Le projet


La SERM met en œuvre et accompagne la réalisation de projets urbains. Le quartier Port Marianne fait partie des 7 secteurs de l’agglomération et constitue un axe de développement majeur de la métropole avec Odysseum. Connaissant un développement urbanistique fort et notamment la construction de nombreux logements, il compte des espaces culturels majeurs, des espaces nature, des infrastructures sociales, des espaces sportifs comme la ou encore des centres de loisirs ou des structures scolaires.

La SERM a retenu setec  pour réaliser la maîtrise d’œuvre pour la conception et la réalisation de la centrale de production d’énergie biomasse avec cycle ORC afin d’alimenter les ZAC Parc Marianne, Rive Gauche, Ilôt de la ZAC J Cœur et le futur quartier République.

Nos missions


The district supplied by the heating network will grow from 43,534 m² in 2011 to more than 460,000 m² by the end of 2022 with an average growth rate of 37,000 m²/year between 2012 and 2022.

The heat network mainly provides heating for the buildings. Domestic hot water is partially provided by solar equipment. The network is linked to the Odysseum power station to power the decentralized adsorption cooling units.

The maximum heating capacity is 5.1 MWh, based on an annual consumption of 30,000 MWh in 2022 for a 460,000 m² habitable net surface area (65 kWh/m²).

Maître d’ouvrage

SERM ( société d'équipement de la région Montpellier)

Chiffres-clés

Périodicité

September 2013 – December 2017

Challenges

This project is innovative in terms of producing electricity from low-temperature heat by combining one of the two wood powered generators with an organic Rankine cycle system. The cooling circuit of this system will be connected to the 90°-60°C network and produce continuous electricity (700 kW). setec  has applied its expertise in organic Rankine cycle systems. This operation is a first in France.
